Heat Exchanger Fabrication — Real Shop-Floor Evidence

Equipment photographed in our GIDC Manjusar-Savli works. End-user names and undocumented performance claims are omitted on purpose.

Multiple shell and tube heat exchangers in the Ohm Engineers manufacturing bay

Shell & tube heat exchangers

Shell-and-tube manufacturing series

Shell and tube heat exchanger with expansion joint during fabrication

Shell & tube with metallic expansion bellow

Fixed-tubesheet exchanger with shell expansion joint

Stainless steel shell and tube heat exchangers on the shop floor

Stainless steel shell & tube heat exchangers

Stainless steel shell-and-tube units

Shell and tube heat exchangers staged outdoors after manufacture

Horizontal shell & tube heat exchangers

Completed exchangers staged for dispatch
